Shop Drawings

A shop drawing is a drawing or set of drawings of certain elements of a project that suggests more important points than construction documents, also provides the Contractor or Architect with visual a specific aspect about what the Sub-contractor or supplier intends to construct or install, earlier than the fabrication or construction of the elements.

We have Engineers, Expert in work with the Steel Fabrication/Erection industries over USA, Canada, UK and Australia. Our completely finished Steel Structural Shop Drawings Services provide Fabrication and Erection drawing sets with all joining details of your project.
Which encompass:

• Anchor Bolt/Marking plan
• General arrangement/ Erection drawings
• Assembly part drawings
• Single part drawings
• Plate grouping drawings
• Girt/ Purlin drawings.
• Bill of materials

General Arrangement drawings

General Arrangement drawings (GA’s) present the overall composition of an object such as a building. Depending on the complexity of the building, this is likely to require a number of different projections, such as plans, sections and elevations, and may be spread across several different drawings. These drawings are likely to be prepared at each stage of development of a building design, showing the overall relationship between the main elements and key dimensions.

Erection drawings

The drawings clearly expose the location and position of a range of assemblies of a specific structure and quite beneficial to personnel in the field of erection. For instance, the erection drawings supply the approximate weight of heavy pieces, the number of pieces, and other helpful data.

Our erection drawings encompass components

• Concrete Footings
• Beams, Columns, Bracings, and other Structural Components
• Decking, Grating
• Anchor Bolt Plans Drawings
• Framing Plans Drawings
• Building Elevations Drawings
• Sectional Elevations Drawings
• Stairs and Elevators Drawings
• Section Details Drawings
• Connection Details Drawings

Assembly Drawings

Assembly Drawings are typically workshop drawings show the welded item made up of different single parts. A typical beam assembly often consists of a beam and a few plates which are welded or bolted to the beam. Assembly drawings will not necessarily show all the plate dimensions but have to be dimensioned in a manner that will allow all parts (plates and beams) to be welded or bolted together. Simply an assembly drawing consists of a main part and secondary parts.
It is virtual steel parts drawing that include list of part and material to be used in building. It gives the perfect idea of steel joints and dimension details to be used in building construction.

Single Part Drawings

Single-part drawings are workshop drawings that exhibit the fabrication details for one part (usually except welds). Single-part drawings usually use small sheet sizes.
Types of steel members includes:

• Steel Column Details
• Steel Beam Details
• Braces Details
• Steel Trusses Details
• Stairs Details
• Handrails Details
• Steel Joists Details

Bill of Materials

Every construction project will require a comprehensive list of parts/material and portions to move a project from the engineering phase to fabrication or final erection. From component level items such as bolts or terminal blocks to sub-assemblies, the integration of advanced Bill of Materials information extraction and reporting will extensively benefit professionals in project administration, estimation, fabrication, installation, and the final construction or manufacturing process. this is actual information of particular member on Shop drawings.
